Matplotlib est l'emblématique package Python qui permet des créer des visualisations avec Python. Matplotlib est une libraire Python de visualisation.
Si vous travaillez avec Anaconda, Matplotlib est déjà installé sinon Matplotlib est disponible sur le répertoire PyPi
!pip install matplotlib
Matplotlib n'est pas une librairie native en Python, il faut l'installer au préalable. Si vous ne l'avez pas encore installée avez pas Pour importer Matplotlib if suffit de faire ceci import matplotlib mais il est plus courant de faire ceci import matplotlib.pyplot as plt. Nous nous concentrerons sur le package .pyplot
import matplotlib
import matplotlib.pyplot as plt
.pyplot
import numpy as np import pandas as pd import matplotlib.pyplot as plt
Généralement, on importe ensemble ces trois librairies
names = pd.Series(["Esso", "Lendjina", "Yemi", "Adboul", "Tracy", "Adjo", "Yacuba", "Degnon"]) countries = pd.Series(["Togo", "Haïti", "Nigeria", "Burkina", "Ivory Cost", "Togo", "Niger", "Benin"]) sexes = pd.Series(['M', 'F', 'M', 'M', 'F', 'F', 'F', 'F']) ages = pd.Series([22, 18, 20,19, 31, 23, 26, 17]) heights = pd.Series([1.73, 1.43, 1.52, 1.82, 1.45, 1.61, 1.90, 1.52])
matplotlib.pyplot.bar
matplotlib.pyplot.barh
plt.bar(labels, values) plt.show() plt.barh(labels, values) plt.show()
matplotlib.pyplot.pie
labels = sexes.value_counts().index values = sexes.value_counts().values plt.pie(x=values, labels=labels, autopct='%.2f') plt.show()
Histograme
# Distribution gaussienne de moyenne 5 et d'écart-type 4 x = np.random.normal(5, 4, 100) plt.hist(x) plt.title("Distribution gaussienne de moyenne 5 et d'écart-type 4") plt.show() # Distribution exponentielle de paramètre lambda=3 x = np.random.exponential(3, 100) plt.hist(x) plt.title("Distribution exponentielle de paramètre lambda=3") plt.show() # Distribution uniforme de paramètres a=4 et b=5 x = np.random.uniform(4, 5, 100) plt.hist(x) plt.title("Distribution uniforme de paramètres a=4 et b=5") plt.show()
Nuage de points
x = np.random.random(100) y = np.random.random(100) plt.scatter(x, y) plt.show()
Courbes
x = np.linspace(-10, 10, 100) y = np.sin(x) plt.plot(x, y, label='sin(x)', color='black') plt.legend(loc='best') plt.show()
from mpl_toolkits.mplot3d import Axes3D X = np.random.normal(2, 3, 100) Y = np.random.uniform(1, 5, 100) Z = np.random.random(100) fig = plt.figure() ax = fig.gca(projection='3d') ax.scatter(X, Y, Z) plt.show()
X = np.linspace(0.1, 10, 100) Y = np.linspace(0.1, 10, 100) Z = np.log(X + Y) fig = plt.figure() ax = fig.gca(projection='3d') ax.plot(X, Y, Z) plt.show()
Z
array([ -inf, -1.59938758, -0.9062404 , -0.50077529, -0.21309322, 0.01005034, 0.19237189, 0.34652257, 0.48005397, 0.597837 , 0.70319752, 0.7985077 , 0.88551907, 0.96556178, 1.03966975, 1.10866262, 1.17320115, 1.23382577, 1.29098418, 1.3450514 , 1.3963447 , 1.44513486, 1.49165488, 1.53610664, 1.57866625, 1.61948825, 1.65870896, 1.69644929, 1.73281693, 1.76790825, 1.80180981, 1.83459963, 1.86634833, 1.89711998, 1.92697295, 1.95596048, 1.98413136, 2.01153034, 2.03819858, 2.06417407, 2.08949188, 2.11418449, 2.13828204, 2.16181254, 2.18480206, 2.20727491, 2.22925382, 2.25076003, 2.27181343, 2.29243272, 2.31263543, 2.33243806, 2.35185614, 2.37090434, 2.38959647, 2.40794561, 2.42596411, 2.44366369, 2.46105543, 2.47814987, 2.49495699, 2.51148629, 2.52774681, 2.54374715, 2.55949551, 2.57499969, 2.59026717, 2.60530504, 2.62012013, 2.63471893, 2.64910767, 2.6632923 , 2.67727854, 2.69107186, 2.70467752, 2.71810054, 2.73134576, 2.74441785, 2.75732125, 2.77006028, 2.78263906, 2.79506158, 2.80733167, 2.81945303, 2.83142922, 2.84326368, 2.85495972, 2.86652054, 2.87794924, 2.88924879, 2.90042209, 2.91147193, 2.922401 , 2.93321192, 2.94390721, 2.95448932, 2.96496061, 2.9753234 , 2.9855799 , 2.99573227])
Pour avoir plus de détails, merci de consulter la documentation officielle Numpy Docs
